Thermal payloads

Sensors

Find heat faults before they fail

Radiometric thermal and long-range zoom for utilities, solar and plant. Stocked in Australia with fitment confirmed against your airframe.

  • Commissioned in Melbourne
  • 12-month warranty
  • Product setup support
View all products

Book a time

Pick a time that suits you.

Methods

How handheld scanning works

Open a topic. Method tables use the same chrome as the model compare.

What thermal is
What thermal is

A thermal payload reads surface temperature differences across an asset or site. That is how you find resistance at joints, overheating plant and heat signatures RGB cannot show.

It does not identify materials and it does not build a survey model. Geometry and colour still need LiDAR or a mapping camera when those are the deliverable.

What you leave with
What you leave with

Find-and-flag workflows use thermal to locate the hot spot, then zoom or EO for evidence. Radiometric cameras give temperatures you can trend in a report when emissivity and distance are set honestly.

Miss the load condition and the fault stays quiet. Fly when the asset is under the load your programme cares about.

Radiometric vs zoom
Radiometric vs zoom

Radiometric stills support trend work and signed numbers when you correct for emissivity, distance and ambient conditions. Zoom optics get you onto the bolt or bushing you care about from a safe standoff.

H30T carries both on one gimbal. H30 keeps the long-range EO path without thermal when temperature is not the deliverable.

Thermal vs UV
Thermal vs UV

Thermal finds resistance under load. UV finds corona discharge. They are different faults on the same corridor.

Many network programmes fly both sensors on the same airframe, or rotate payloads by season. We map the pair against the inspection standard you invoice.

Methods compared
Methods compared

Tick means it wins often. Dash means it can work with the right plan. Cross means it is usually the wrong tool.

Use case Thermal UV corona RGB / EO zoom
Resistance under load
Corona / discharge
Solar string anomalies
Visual bolt / bushing ID
Night search / low light
Survey geometry / GSD
After the flight
After the flight

Capture in DJI Pilot 2. H30T radiometric stills process in DJI Thermal Analysis Tool, or through Thermalmapper when you want inspection products tied to your asset language.

We wire the export you actually invoice during handover. Same engineers stay on support after commissioning.

By job

Applications

Pick the job closest to yours.

Compare

Compare models

Spec
DJI Zenmuse H30T
DJI Zenmuse H30
CZI C30N Night Vision
RoleZoom + radiometric thermalZoom-led inspection EONight vision camera
SensingEO zoom + IREO zoom + LRFLow-light EO
RadiometricYes (1280×1024 class)NoNo
ZoomLong-range optical + digitalLong-range optical + digitalNight-optimised path
Typical jobsUtilities, solar, public safetyVisual inspection, pin-pointAfter-dark search and EO
From$17,335$7,786$31,968
Fitment familyMatrice 300 / 350Matrice 300 / 350Confirm on quote

Outcome

What you walk away with

You leave with a payload matched to the aircraft, Pilot 2 presets for the inspection you sell, and Australian warranty from the same team that confirmed fitment.

Book a demo when you want the workflow on a real asset before you buy.

Questions, answered

Choosing

Should I buy Zenmuse H30 or H30T?
H30 if the billable output is long-range visible zoom and laser pin-pointing without thermal. H30T if you also need radiometric thermal on the same gimbal. Public safety, utilities and fire often land on H30T. Pure visual inspection can stay on H30. We route from the deliverable, not the brochure feature list.
Thermal or UV for powerline inspection?
Thermal finds resistance under load. UV finds corona discharge. They are different faults. Carry both when the programme inspects for both, or rotate payloads by season.
When is C30N the better pick than H30T?
When night vision and low-light EO are the primary job and radiometric thermal is secondary or absent. C30N is a specialist night path. For daytime utility and solar heat work, H30T is the usual dual zoom-and-thermal payload.
Do I need radiometric data?
Yes if you trend temperatures or write numbers into a report. Zoom-only or non-radiometric thermal can be enough for find-and-flag workflows where the deliverable is locate and photograph, not a signed temperature.

Buying

What does a Zenmuse H30T cost in Australia?
From $17,335 AUD on this page (incl. GST, Melbourne stock). Final kit price depends on aircraft, accessories and Care. Ask for a configured quote when you compare landed kit totals.
Do you sell the payload alone or only as a full kit?
Either. Payload-only when you already fly a compatible Matrice. Full kit when you need airframe, controller and handover in one order. We confirm fitment before quoting.
Can I demo the thermal workflow before buying?
Yes. Book a demo or workflow review. Bring the asset type and the aircraft you fly. We would rather prove the capture and report path than sell a sensor that sits on a shelf.

Compatibility

Which aircraft does H30 / H30T fit?
H30 Series mounts on Matrice 350 RTK and Matrice 300 RTK with DJI RC Plus. Matrice 400 and docked Matrice 4D programmes often use different native sensors. We confirm the path against your next buy cycle before you order.
Will this fit Matrice 4D or Dock 3?
Selected thermal packages can. Product pages list fitment. We confirm against your dock and airframe before quoting so you do not buy the wrong gimbal path.

Accuracy

How accurate are the temperature numbers?
Absolute temperature depends on emissivity, distance, ambient conditions and calibration. Treat brochure numbers as a starting point, not a signed-off reading. We set Pilot 2 defaults and teach correction habits at handover.

Workflow

What does capture to client report look like?
Capture in DJI Pilot 2. Visible and thermal stills land on card. H30T R-JPEGs process in DJI Thermal Analysis Tool, or through Thermalmapper when you want inspection products tied to your asset language. We wire the export you invoice during commissioning.

Support

What warranty and support do I get?
A 12-month warranty backed by Australian Consumer Law, with support from our Melbourne team. The same engineers who matched the payload to your airframe and ran handover stay on the phone. DJI Care Enterprise is available where eligible.
Next step

Local support, end to end

From spec to deployment to processing, talk to a team that flies and scans for a living. We'll get you capturing faster.
